| Cartridge Model | Top Cap OD mm | Top Cap ID mm | Bottom Cap OD mm | Bolt Hole mm | Height mm | Filtration Surface ㎡ |
| TRLF/Z 3266 | Φ324 | φ213 | Φ324 | φ14 | 660 | 21 |
| TRLF/V 3266 | Φ408 | φ293 | Φ324 | / | 660 | 21 |
| TRLF/P 3266 | Φ324 | φ213 | Φ324 | φ14 | 660 | 9.4 |
| TRLF/P 3566 | Φ352 | φ241 | Φ352 | φ16 | 660 | 10 |
