| Cartridge Model | Top Cap OD mm | Top Cap ID mm | Bottom Cap OD mm | Bolt Hole mm | Height mm | Filtration Surface ㎡ | Installation Way |
| TRLF/P 3292 | Φ324 | φ213 | Φ324 | φ25 | 924 | 16 | Bottom to Top |
| TRLF/P 32100 | Φ324 | φ213 | Φ324 | / | 1000 | 16 | Top to Bottom |
| TRLF/P 35100 | Φ352 | φ241 | Φ305 | / | 1000 | 17 | Top to Bottom |
| TRLF/P 40145 | Φ406 | φ292 | Φ306 | / | 1000 | 28 | Top to Bottom |
