Pleated filter cartridges are made of pleated polyester filter media for low pressure drop, increased surface area and longer life.
Features
● Pleated design increased surface area and contaminant removal
● Longer filtration runs for fewer change-out and less maintenance
● Low pressure drop
● Designed for general water filtration purposes
Specifications
●Filter media: Polyester, PP,Cellulose
● Outside diameter: 68mm,115mm
● Inner diameter: 28mm
● Length:10", 20", 30", 40"
● End cap: PU/Plastisol
● Core: PP
● Removal Rating: 1µm,5µm,10µm,20µm,50µm
● Max Operating Temperature: 37.8 ℃
● Maximum Operating pressure: 4.0 bar
● Flow Rate per 10" cartridges: 3-10GPM,depend on removal rating
Applications
● general water and R.O treatment
● food and beverage
● acid-base liquid in chemical processing
● industrial chemicals and organic solvents
● processing of sterile water and ultrapure water
● industrial water and plating liquid
Order information:
