General Description:
Big Blue Pleated filter cartridges are made of pleated polyester filter media for low pressure drop, increased surface area and longer life
Applications：
● General water and R.O treatment
● Food and beverage
● Acid-base liquid in chemical processing
● Industrial chemicals and organic solvents
● Processing of sterile water and ultrapure water
● Industrial water and plating liquid
Features：
● Pleated design increased surface area and contaminant removal
● Longer filtration runs for fewer change-out and less maintenance
● Low pressure drop
● Designed for general water filtration purposes
Specifications:
Dimensions
● Outside diameter: 115mm
● Inner diameter: 28mm
● Length:9.75”,9.87”,10", 20", 30", 40"
Material Of Constructions:
● Filter media: Polyester, PP,Cellulose
● End cap: PU/Plastisol
●Core: PP
Performance:
● Removal Rating: 1µm,5µm,10µm,20µm,50µm
● Maximum Operating Temperature: 37.8 ℃
● Maximum Operating pressure: 4.0 bar
● Flow Rate per 10" cartridges: 3-10GPM,depend on removal rating
